ThermRite PRO Underfloor Heating Overlay Boards

Shop ThermRite PRO boards, dual-purpose underfloor heating overlay panels, EPS400 UFH boards and foil-faced underfloor heating panels at ThermRite Shop. ThermRite PRO panels are designed for low-profile water underfloor heating installations where strong heat output, minimal floor build-up and flexible floor finish compatibility are required.

This collection includes ThermRite PRO 16mm and 20mm panels, ThermRite PRO adhesive and multi-surface primer. The panels use a high-strength EPS400 insulation core with a factory-bonded 200-micron aluminium foil layer to support efficient heat transfer. They are suitable for retrofit projects, renovations, new installations and floor finishes including tile, vinyl, wood and laminate when installed correctly.

Which ThermRite PRO Product Should I Choose?

Use the table below to compare the ThermRite PRO boards and installation accessories available in this collection.

Product Best For Key Features Shop
ThermRite PRO 16mm UFH Panel Very low-profile retrofit projects where minimal floor height increase is important. 16mm EPS400 dual-purpose panel with 200-micron foil, designed for 12mm pipe at 120mm centres. View 16mm PRO board
ThermRite PRO 20mm UFH Panel Low-profile water UFH installations needing deeper insulation and 16mm pipe compatibility. 20mm EPS400 dual-purpose panel with 200-micron foil, designed for 16mm pipe at 150mm centres. View 20mm PRO board
ThermRite PRO Adhesive - 500ml Bonding PRO boards to a stable existing floor for tile, vinyl or bonded floor finishes. Adhesive designed for ThermRite PRO panel installation where bonded fixing is required. View PRO adhesive
PRIME IT Multi Surface Primer - 5 Litre Preparing floors before fitting boards, adhesives, levelling compound or floor finishes. 5 litre multi-surface primer for improving surface preparation before installation. View primer

Key Benefits of ThermRite PRO Boards

Low-Profile Floor Build-Up 16mm and 20mm panel options help keep floor height increases low, making them suitable for retrofits, renovations and height-restricted spaces.
Dual-Purpose Floor Finish Compatibility ThermRite PRO boards can support tile, vinyl, wood and laminate floor finishes when installed in line with the correct floor build-up guidance.
EPS400 High-Strength Core The rigid EPS400 insulation core provides strength, stability and insulation performance for water underfloor heating installations.
200-Micron Aluminium Foil Layer The factory-bonded foil layer helps spread heat across the panel surface and improve upward heat transfer into the room.
No Extra Pipe Fixings Required Pre-formed grooves help retain UFH pipe securely, reducing the need for separate pipe clips or rails.
Trade & Domestic Use Suitable for installers, contractors and homeowners working on low-profile water underfloor heating systems.

ThermRite PRO 16mm vs 20mm Boards

Both ThermRite PRO panels are dual-purpose foil-faced overlay boards for water underfloor heating. The 16mm panel is best where the lowest possible build-up is required and uses 12mm pipe. The 20mm panel offers slightly deeper insulation and is designed for 16mm pipe. Both boards use 150mm pipe centres and are suitable for a range of floor finishes when installed correctly.

Board Pipe Size Best For
ThermRite PRO 16mm 12mm UFH pipe Very low-profile overlay systems, retrofits and rooms with limited floor height.
ThermRite PRO 20mm 16mm UFH pipe Low-profile UFH systems needing larger pipe and slightly deeper insulation.

Best Uses for ThermRite PRO Panels

Retrofit Underfloor Heating ThermRite PRO boards are ideal for adding water UFH over stable existing floors where a low build-up is required.
Renovations & Extensions Use PRO panels for low-profile floor heating in property upgrades, extensions and room refurbishments.
Tile, Vinyl, Wood & Laminate Floors The dual-purpose design supports multiple floor finish options, helping simplify product choice when the final floor covering is not yet confirmed.
Low-Height Floor Build-Ups Choose 16mm or 20mm panels where door thresholds, ceiling heights or existing floor levels limit available build-up.

Frequently Asked Questions

What are ThermRite PRO boards? ThermRite PRO boards are low-profile water underfloor heating overlay panels made from EPS400 insulation with a 200-micron foil layer and pre-formed pipe grooves.
What is the difference between 16mm and 20mm ThermRite PRO boards? The 16mm panel is designed for 12mm UFH pipe and the lowest build-up. The 20mm panel is designed for 16mm UFH pipe and provides slightly deeper insulation.
Can ThermRite PRO boards be tiled over? Yes, ThermRite PRO panels can be used with tiled floor finishes when installed with the correct adhesive, primer and floor build-up guidance.
Can I use ThermRite PRO boards with wood or laminate flooring? Yes, ThermRite PRO panels are dual-purpose boards suitable for wood and laminate floating floor finishes when installed correctly.
Do ThermRite PRO boards need adhesive? Adhesive is normally used when bonding PRO boards to a stable existing floor for tile, vinyl or bonded finishes. For some floating wood or laminate floor build-ups, adhesive may not be required.
